Mô tả sản phẩm
1/3” Analog Color Video Camera
Vicam6.0
Vicam6.0 is the 1/3″ analog color CCD camera for Sinowon manual/semi-auto vision measuring system, it has been applied on the series of iMove, iVision, iFocus, iTouch, and iSemi.
Technical Specifications：
| Commodity | 1/3” Analog Camera of Vision Measuring Machine |
| Model | ViCam6.0 |
| Video Signal System | Type E: PAL |
| Sensor | Diagonal 6.0mm 1/3” Exview CCD |
| Unit cell size | 6.5um(H)X6.25um(V) |
| Number of pixels | approx. 470K pixels |
| Scanning system | 2:1 interlaced |
| Resolution | 650TVL |
| Video output | composite video signal: 1.0Vp-p, 75 ohms |
| Video process | Bio-ele image processing ele ext-Fx TM |
| Sensitivity | 0.1Lux |
| S/N ratio | 54dB (AGC: OFF) |
| ATW | OSD set: Push lock/ manual/auto(1800 °K~10500 °K) |
| AES | OSD set: 8-level manual/auto: 1/50s~1/10,0000s |
| OSD | available |
| Sync mode | internal lock |
| Lens drive | DC |
| Lens mount | C/CS mount |
| Power consumption | Approx. 1.5W; recommended: +12VDC |
| Operating temperature | 0℃ to +40℃ (recommended) |
| Dimension | 60.0 (L)×48.5 (W)×58.0 (H) mm |
| Weight | approx. 155g |
1/2” Analog Color Video Camera
Vicam8.0
Vicam8.0 is the 1/2” analog color video CCD camera for Sinowon automatic vision measuring system, it has been applied on the series of AutoVision, AutoTouch, AutoScan as the standard camera.
Technical Specification:
| Commodity | 1/2” Analogue Color Video Camera |
| Model | Vicam8.0 |
| Signal system | Type E: PAL standard |
| Sensor | 1/2” 8.6um(H)X8.3um(V) |
| Number of pixels | Approx.470K pixels |
| Scanning system | 2:1 interlaced |
| Resolution | 700TVL |
| Video output | composite video signal: 1.0Vp-p, 75 ohms
Y:0.7Vp-p, 75 ohms: C:0.3Vp-p 75 ohms |
| Video process | ele ext-Fx |
| Sensitivity | 0.001Lux |
| S/N ratio | 63dB (AGC: OFF) |
| ATW | OSD set: Push lock/ manual/auto(2300° K~11000° K) |
| Image adjustment | OSD set, Brightness, contrast ratio, and sharpness, Chroma, gain |
| Language | OSD set,8 English/Chinese/France/German/Portuguese/Spanish |
| OSD | Available |
| Sync mode | internal lock |
| Lens drive | DC |
| Lens mount | C/CS mount |
| Lightening proof | isolated 10/700us 4000V; follow IEC61000-4.5, ITU-T K20/21 |
| Power consumption | approx. 2.4W +12V DC |
| Operating temperature | 0℃ to ~40℃ |
| Dimension | 127.1 (L)×68.8 (W)×48.7 (H) mm |
| Weight | approx. 400g |
